A Beginner-Friendly Wing For Powered Paragliding:
APPROVED: ULM
100%
“The Dudek Warp is a versatile wing for both free flying and powered flight. ULM Approved, it is ideal for beginner & intermediate Pilots.”
Dudek WARP Paraglider SPECS:
WARP – sizes | 15 |
16 | 17 |
18 | 20 | 22 | 24 |
Approval – ULM Identification | pending | pending | pending | pending | pending | pending | pending |
Number of cells | 62 | ||||||
Wing area flat [m2] | 15.00 | 16.00 | 17.00 | 18,00 | 20,00 | 22,00 | 24,00 |
Wing area projected [m2] | 12.76 | 13.61 | 14.46 | 15.31 | 17.01 | 18.71 | 20.41 |
Wingspan flat [m] | 9.43 | 9.74 | 10.04 | 10.33 | 10.89 | 11.42 | 11.93 |
Wingspan projected [m] | 7.58 | 7.83 | 8.07 | 8.30 | 8.75 | 9.18 | 9.59 |
Aspect ratio flat | 6.00 | ||||||
Aspect ratio projected | 4.50 | ||||||
Speed* [km/h] | min = 31 ; trim = 48-65 ; max = 80 (+/- 3 km/h)* | ||||||
Lines + risers length[m] | 5.50 | 5.68 | 5.86 | 6.03 | 6.35 | 6.66 | 6.96 |
Total lines length [m] | 204.3 | 211.22 | 212.87 | 219.38 | 231.88 | 243.77 | 255.14 |
Total ake-off weight** [kg] | 75-100** | 80-105** | 85-110** | 90-115** | 100-125** | 110-135** | 120-145** |
Max take-off weight – for experienced*** [kg] | 120*** | 125*** | 130*** | 135*** | 145*** | 155*** | 165*** |
Canopy weight [kg] | 3.95 | 4.18 | 4.34 | 4.50 | 4.80 | 5.10 | 5.44 |
Distance between risers [cm] | 45 | 45 | 45 | 45 | 45 | 45 | 45 |
Lines | A-8000U: 050; 070; 090; 130; 190 / Technora: 190; 280 / Dyneema: 350 | ||||||
Cloth | Porcher Sport 38 g/m2, Dominico tex 34 g/m2, Porcher Sport Hard 40 g/m2, SR Scrim, SR Laminate 180 g/m2 |
* Speeds are given as estimated for the middle wing size and the middle of its weight range. These speeds can vary within +/- 3 km / h depending on the size, take-off weight and additional factors such as air pressure and temperature.
** The basic rule is to choose the size of the wing so that the take-off weight is in the middle of the weight range. Less weight on the wing (lower range take-off weight) can be considered for foot take-off, when flying in calmer conditions, or when we want to improve economy. More experienced pilots who want to fly dynamically, have higher speed and fly in more demanding wind conditions can consider greater wing loading (take-off weight in the upper range). This is a common option among trike users.
*** Note – the canopy significantly changes its behavior with increasing wing loading. The greater the loads, the greater skill and concentration of the pilot are required.
Dudek WARP 2 Paraglider PRICING & DETAILS:
INCLUDES:
- Transport bag with compression strap.
- Easy Catch speedbar
- etui with documents and repair kit (self-adhesive cloth, spare line)
- wind ribbon and windsock
- small gifts
